Pz90 1415287727

USE:

* 2-way connections with angles up to 50° - 130°

works with

PZ 22, PZ 27, PZ 35, PZ 40, PZC 13, PZC 14, PZC 18, PZC 19, PZC 25, PZC 26, PZC 28

steel grade
ASTM Grade 50/60,
ASTM A690 MARINER® steel
weight
~ 7.36 lb/ft
~ 11.2 kg/m

In stock (or comparable product).

Place an order »

downloads

Need To Build a Sheet Pile Wall?

Configure a Solution on iSheetPile.com.


Installation

  1. Please review the proper interlocking examples that are listed.
  2. Thread the connector into the interlock while the sheet pile is out of the ground.
  3. Adjust the connector to the appropriate position.
  4. Tack or spot-weld the connector in place. Typically, a ~250mm (~10") weld attaching the connector to the sheet pile to the top is sufficient.
  5. Drive/extract the sheet pile (with the connector attached) as you would normally.
